Mini Rotavators & Rotavators
| MODEL | 751 |
| Work Length Of weeder (mm) | 1852 |
| Overall Width of Weeder (mm) | 1000 |
| Overall Length of Weeder (mm) | 2050 |
| Working Area in 1 Row (mm) | 395 |
| Non Work Area Btw 1 Row (mm) | 305 |
| Thickness of Side Plates (mm) | 8 |
| Trailing Board Type | Hinged |
| Type of Drive | Gear Drive |
| Driver Gear | 24 Teeth |
| Idler Gear | 35 Teeth |
| Driven Gear | 28 Teeth |
| Distance Btw 2 Flanges (mm) | 155 |
| Oil Capacity of Gearbox | 3Ltr, EP-140 |
| No. of Blades on Flanges (pcs) | 6 |
| Upper Housing Bearing | 6213 |
| Rotor Housing Bearing | 6310 |
| Type of Gearbox | Multi speed / single speed |
| Thickness of Body (mm) | 4 |
| Thickness of Dalla (mm) | 3 |
| Type of Blade & Weight | L-SHAPE, 590 kg approx |
| No of Flanges in each Row | 2 |
| DIA of Flanges (mm) | 215 |
| Thickness of Flanges (mm) | 11 |
| MODEL | PARAM 411 |
| ROTAVATOR SIZE | 4 FEET |
| SIDE THICKNESS OF PLATE | 8mm, 8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| THICKNESS OF DALLA | 3mm |
| THICKNESS OF BODY | 3mm |
| NO. OF ROTOR BLADE | 22 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 5 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| OIL CAPACITY IN GEAR BOX | 2.5 Itr. EP-140 |
| SIDE DRIVER & IDLER GEAR | 20 TEETH, 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| TRACTOR HP | 25HP & Above |
| MODEL | PARAM 511 |
| ROTAVATOR SIZE | 5 FEET |
| SIDE THICKNESS OF PLATE | 10mm, 8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| SIZE OF DALLA | 1565mmX500mm |
| THICKNESS OF DALLA | 3mm |
| THICKNESS OF BODY | 4mm |
| NO. OF ROTOR BLADE | 42 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 6 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 11 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 22 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| BEVEL SIDE BEARING | TAPER ROLLER 30215 |
| PINION SIDE BEARING | TAPER ROLLER 32210 |
| SIDE DRIVER & IDLER GEAR | 20 TEETH, 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| ROTAVATOR LENGTH | 1648mm |
| ROTAVATOR WIDTH | 1040mm |
| ROTAVATOR HEIGHT | 1070mm |
| ROTAVATOR WEIGHT | 455 kg approx |
| TRACTOR HP | 35HP & Above |
| PTO 540, 1000 RPM GEAR BOX GEAR | 17-18 TEETH, 12-23 TEETH |
| MODEL | PARAM 611 |
| ROTAVATOR SIZE | 6 FEET |
| SIDE THICKNESS OF PLATE | 10mm,8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| SIZE OF DALLA | 1830mmX500mm |
| THICKNESS OF DALLA | 3mm |
| THICKNESS OF BODY | 4mm |
| SIZE OF ROTOR | Length 1735 X dia 90mm |
| NO. OF ROTOR BLADE | 48 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 8 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 11 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 22 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| BEVEL SIDE BEARING | TAPER ROLLER 30215 |
| PINION SIDE BEARING | TAPER ROLLER 32210 |
| SIDE DRIVER GEAR | 20 TEETH |
| SIDE IDLER GEAR | 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| ROTAVATOR LENGTH | 2146 mm |
| ROTAVATOR WIDTH | 1100mm |
| ROTAVATOR HEIGHT | 1070mm |
| ROTAVATOR WEIGHT | 480 kg approx |
| TRACTOR HP | 35-45HP |
| PTO 540, 1000 RPM GEAR BOX | 17-18 TEETH, 12-23 TEETH |
| MODEL | PARAM 711 |
| ROTAVATOR SIZE | 7 FEET |
| SIDE THICKNESS OF PLATE | 10mm,8mm |
| SIZE OF BOLT | 10mmX12mmX14mmX16mm |
| SIZE OF DALLA | 2134mmX500mm |
| THICKNESS OF DALLA | 3mm |
| THICKNESS OF BODY | 4mm |
| SIZE OF ROTOR | Length 2013 X dia 90mm |
| NO. OF ROTOR BLADE | 54 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 9 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 11 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 22 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| BEVEL SIDE BEARING | TAPER ROLLER 30215 |
| PINION SIDE BEARING | TAPER ROLLER 32210 |
| SIDE DRIVER GEAR | 20 TEETH |
| SIDE IDLER GEAR | 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| ROTAVATOR LENGTH | 2400 mm |
| ROTAVATOR WIDTH | 1100mm |
| ROTAVATOR HEIGHT | 1070mm |
| ROTAVATOR WEIGHT | 435 kg approx |
| TRACTOR HP | 45- 55HP |
| PTO 540, 1000 RPM GEAR BOX | 17-18 TEETH, 12-23 TEETH |
| MODAL | PARAM 811 |
| ROTAVATOR SIZE | 8 FEET |
| SIDE THICKNESS OF PLATE | 10mm,8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| SIZE OF DALLA | 2440mmX500mm |
| THICKNESS OF DALLA | 3mm |
| THICKNESS OF BODY | 4mm |
| SIZE OF ROTOR | Length 2305 X dia 90mm |
| NO. OF ROTOR BLADE | 60 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 10 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 11 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 22 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| BEVEL SIDE BEARING | TAPER ROLLER 30215 |
| PINION SIDE BEARING | TAPER ROLLER 32210 |
| SIDE DRIVER GEAR | 20 TEETH |
| SIDE IDLER GEAR | 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| ROTAVATOR LENGTH | 2654 mm |
| ROTAVATOR WIDTH | 1100mm |
| ROTAVATOR HEIGHT | 1070mm |
| ROTAVATOR WEIGHT | 560 kg approx |
| TRACTOR HP | 55-60HP |
| PTO 540, 1000 RPM GEAR BOX | 17-18 TEETH, 12-23 TEETH |
| MODEL | PARAM 911 |
| ROTAVATOR SIZE | 9 FEET |
| SIDE THICKNESS OF PLATE | 10mm, 8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| THICKNESS OF DALLA | 4mm |
| THICKNESS OF BODY | 5mm |
| SIZE OF ROTOR | 70 X 90mm |
| NO. OF ROTOR BLADE | 66 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 11 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 13 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 23 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| SIDE DRIVER GEAR | 20 TEETH |
| SIDE IDLER GEAR | 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| TRACTOR HP | 65HP & Above |
| PTO 540, 1000 RPM GEAR BOX REDUCTION GEAR | 17-18 TEETH, 12-23 TEETH |
| MODEL | PARAM 1011 |
| ROTAVATOR SIZE | 10 FEET |
| SIDE THICKNESS OF PLATE | 10mm, 8mm |
| SIIZE OF BOLT | 10mmX12mmX14mmX16mm |
| THICKNESS OF DALLA | 4mm |
| THICKNESS OF BODY | 5mm |
| SIZE OF ROTOR | 70 X 90mm |
| NO. OF ROTOR BLADE | 72 nos. |
| TYPE OF ROTOR BLADE | L-SHAPE |
| NO. OF FLANGE | 12 nos. |
| TYPE OF FLANGE | M.S CIRCULAR PLATE |
| NO. OF SKIDS | 2 nos. |
| TYPE OF GEAR BOX | BEVEL GEAR MULTI SPEED |
| NO. OF TEETH ON PINION | 13 TEETH |
| NO. OF TEETH ON BEVEL GEAR | 23 TEETH |
| OIL CAPACITY IN GEAR BOX | 3.5 Itr. EP-140 |
| SIDE DRIVER GEAR | 20 TEETH |
| SIDE IDLER GEAR | 35 TEETH |
| SIDE DRIVEN GEAR | 28 TEETH |
| OIL CAPACITY IN SIDE GEAR | 3.5 Ltr. EP-140 |
| 11 NO. HOUSING BEARING | 1 nos. 6311 |
| 9 NO. HOUSING BEARING | 1 nos. 6309 |
| 35 TEETH GEAR IDLER BEARING | 2 nos. 30209 |
| TRACTOR HP | 75HP & Above |
| PTO 540, 1000 RPM GEAR BOX REDUCTION GEAR | 17-18 TEETH, 12-23 TEETH |
